ATLAS II Visual Audible Altimeter




ATLAS II Visual Audible Skydiving Altimeter.

The ATLAS II is an electronic altimeter with a digital display which can be used as either an audible or visual altimeter.

The ATLAS II, the evolution of the famous menu driven Alti-2 Neptune, is now available with the world wide standard USB-C port for recharging every 4-8 weeks. The ATLAS II comes with new button you can use even with gloves on. They are so clicky!

Thanks to the no battery/filters/maintenance of the ATLAS II, the altimeter has low cost of ownership. Taking the advantage of the tactical heritage, the ATLAS II withstands drop tests from 6 feet (1.2 m) with 1000+G and is waterproof up to 6 feet for one hour. The machined metal case is from aircraft aluminum.

The ATLAS II has added logbook features of 200 jumps, a training mode for AFF ground training and a manual mode for your convenience.

The ATLAS II is menu driven. Spend time skydiving – not reading manuals!


Ruggedized machined aluminum case with reduced edges and corners
Improved USB charging and data transfer through waterproof USB-C
ECO friendly. Safe more than 100 Dollars on single use batteries over 10 years
Raised easy-push clicky buttons with protective case recess
Waterproof up to six feet for up to one hour

Eight alarm groups; Includes both free fall and/or canopy alarms
Canopy alarms include approach alarms preceding each selected alarm altitude
Canopy alarm volume is adjustable for those who wish to hear alarms from their wrist

Logs over 200 jump Profiles and over 2,500 jump Summaries
Jump odometer for fast-paced training days
Time under canopy and free fall time are logged
USB-C for connection to different types of third party applications.

Time can be set to 12 or 24 hour format
Date can be set to USA or International format
Temperature can be displayed in F or C
Speed can be displayed in mph or kmh
LCD may be flipped
Menu scrolls and wraps
Electroluminescent Backlight

Free fall Alarm Group
Canopy Alarm Group
Exit Altitude
Canopy Deployment Altitude
Free Fall Time
Canopy Time
Average Speed
Speed at four different altitudes
The adjustable hand mount for the ATLAS II is included.

Every sport altimeter that leaves Alti-2 production in DeLand, Florida or in the UK are individually tested in a pressure chamber including video evidence before they ship out! Trusting your altimeter should be justified.

2.44” x 1.69” x .47”

1.4 oz (without mount)

-20° C to +60° C

Max Depth (Waterproofing)
6 feet 1 hour

Body Material
Machined Aluminum

Battery Type
Rechargeable Lithium Ion

Currently available in Black ONLY

Additional information

Additional information

Weight .3 kg

Black, Purple *Special Edition*
